Three-auger vertical trailer MV-DC Triplo series Belt + Door

Products / Three-auger vertical trailer MV-DC Triplo series Belt + Door

• Vertical mixer
• 3 vertical augers with toothed knives and
HARDOX reinforced scrapers.
• 4 adjustable counter knives
• Vertical ladder with access from both sides.
• Gear change (servo assisted)
• Programmable scale (15 rations, 15 ingredients)
• 6 weighing cells of Ø54 mm
• Hydraulic stand with manual pump
• Hydraulic and manual brake
• Single cardan shaft
• Height adjustable bolted hitch
• Gear change for 200 CV hydraulic

• Solid anti-overflow ring.
• Discharge through two side doors
• Gear reducer:

MV30T and MV35T PGA-2102
MV40T and MV45T PGA-2502

• Tyre: Type 435/50 R 19.5

MV 30 T and MV35 T TANDEM (2 axles. Steered rear axle)

MV40 T and MV45 T TRIDEM (3 axles. First and third forced directional axles, manual and hydraulic brake).

• No hydraulic unit. Quick coupler connection to the tractor.

ADVANTAGES

triplo cinta delantera (1)

triplo cinta delantera (3)

triplo cinta delantera (2)

triplo cinta delantera (10)

triplo cinta delantera (5)

triplo cinta delantera (11)

triplo cinta delantera (9)

triplo cinta delantera (6)

triplo cinta delantera (7)

triplo cinta delantera (8)

3sinfin-mv-dc-sección-hztal

3sinfin-mv-dc-seccion-lateral

HYDROSHIFT
